Model 3560 Ultra-High Flow Pipeline Regulator

Stock Code:
4000962
$1,799.00 ex gst

Lead time required for the assembly of some products.

Description



Model 3560-250 Ultra-High flow Pipeline Single-Stage Regulator (250PSIG)



• Outlet Pressure: 0-250PSIG, 0-1,700kPa

• Suitable for use with non-corrosive gases

• Provides ultra-high flows for pipeline, manifold and bulk systems

• Brass bar stock body and bonnet for longer service life

• Neoprene diaphragm for improved pressure control

• One-piece encapsulated seat design with internal filter to protect the neoprene seat from particulate contamination

• Ergonomic ABS plastic knob for easy adjustments

• 2.5" brass dual scale (psi/bar) easy-to-read gauge

• 8 ports: (2) 1/2" NPT, (6) 1/4" NPT

• 1/2" NPT (F) inlet/outlet connections

• CGA E-4 certified

• Rear panel mountable
