Cutting Guide - Straight & Circular (CT Style)

Stock Code:
IR693B-HC
$113.88 ex gst

Lead time required for the assembly of some products.

Description



Model IR693B-HC Cutting Guide



Harris® Circle Cutting Attachment Is Designed For Cutting Circles Up To 30" Diameter And Straight-Line Cutting. It Comes With Adjustable Wheels And Provides Quality Cuts.



Features:



• Harris Compatible Tip Nut (CT Style Tips)

• Yields Higher Quality Cuts With Hand Torches

• Features Straight-Line Cutting

• Cutting Circles Up To 30" (762mm) In Diameter

• Straight Line Cutting/Burning

• Adjustable Wheels To Match Torch Height

• No Tangled Hoses Due To Swivel Nut Performance



Dimensions:



• 13.80mm Cutting Side Inner Diameter

• 28mm Mounting Nut Outer Diameter

• 63mm Overall Height

• 122mm Overall Width

• 314mm Radius Bar

• 21mm Tip Nut Inner Diameter

• 30mm Wheel Width



Make an Enquiry
